The QM-GK panel PC series is designed for heavy industrial uses that need high degree of computing. Integrated with 12th Gen Intel Core processor, the panel PC supports up to 64GB DDR4 memory, Intel® UHD Graphics and a PCIe Gen4 x16 slot for expansion of functionality. Its IP65 projected capacitive touchscreen with anti-glare/UV coating not only ensures readability and durability, but also allows gloved/wet hand operation. Moreover, the built-in power supply with AC input simplifies power delivery to the system and maximizes energy efficiency for diverse applications such as edge AI, industrial automation or machine vision.
The QM-GK is integrated with 12th Gen Intel® Core™ i7/i5/i3/Pentium® processor (code name: Alder Lake-S) and Intel® H610 chipset. Supporting up to 12 cores and 4.9GHz burst frequency, the QM-GK series can provide high performance, real-time edge computing to achieve unparalleled IoT workload consolidation and AI inferencing. The integrated Intel® UHD Graphics 770* driven by Intel® Xe Architecture with up to 32 graphics execution units (EUs) enhances graphics performance, allowing the industrial panel PC to display pixel-accurate visuals and better support imaging applications.
* Graphics specifications may vary depending on the CPU installed.
The QM-GK features a rugged and true-flat front screen equipped with heavy-duty waterproof gasket seal on the back to resist pressure water jets. It is easy to maintain and keep clean, making it an ideal industrial computing terminal for harsh sanitary-critical environments such as food processing factories.
Protected from total dust
ingress
Protected from low pres-
sure water jets from any
direction
Strong waterproof gasket
around the back of the
frame
Maximize the display;
minimize installation space
MTBF: 70000 hrs
Luminuance: 450 nits
Qtenboard rugged touchscreen adopts glass-glass PCAP touch technology with industrial-grade touch controllers optimized for harsh industrial scenarios. QM-GK series industrial panel PCs equipped with PCAP touch support gloved operation, perfectly suited for food processing, chemical and beverage manufacturing environments.
The industrial touch display supports 10-point multi-touch, recognizing and responding to ten simultaneous touch points. Developers can build applications requiring complex gestures including zoom, rotate and swipe, and support multi-person collaborative operation on one panel PC.
Qtenboard PCAP touchscreen delivers excellent optical clarity and high contrast ratio. Integrated anti-glare and anti-UV coating eliminates screen reflection, maintaining clear visuals and resisting scratches during long-term outdoor and high-brightness operation.
With 87% high light transmittance, the touch glass ensures outstanding image clarity and excellent screen readability under complex lighting conditions.
Persistent surface protection keeps display visuals crisp. QM-GK series adopts 7H hardness chemically strengthened glass, effectively preventing scratches caused by tools and sharp objects, extending service life and stabilizing touch precision for industrial scenarios.
Optimized touch sensitivity enables reliable operation with thin rubber and standard work gloves. The PCAP touch surface is easy to clean and requires no frequent touch calibration during long-term continuous operation.
PU Coated Gloves
(Thickness: 0.9 mm)
Anti-Static Gloves
(Thickness: 1.05 mm)
Medical Latex Gloves
(Thickness: 3~5 mil)
Anti-Static Gloves
(Thickness: 0.6~0.8 mm)
*Thick cloth, leather gloves may require touch firmware adjustment for stable operation. Multi-touch points may be limited when using thick gloves (e.g. reduced to 2 simultaneous touch points).
Outdoor deployment exposes touch screens to continuous direct sunlight and ultraviolet radiation, which may cause coating cracking, hazing, yellowing and bubbling. Qtenboard anti-UV PCAP touch solution is customized for long-term sun-exposed outdoor industrial equipment with reliable UV resistance properties.
Powered by Intel® UHD Graphics with up to 32 EUs, QM-GK series supports secondary display connection via HDMI 2.0 port, delivering robust hardware decoding and pixel-perfect 4K resolution output.
The QM-GK industrial panel PC features a PCIe Gen4 x16 slot offering high-bandwidth expansion for GPU cards, SSDs, frame grabbers and AI accelerator modules. Direct CPU connection eliminates chipset transmission bottlenecks and lowers latency. Running at 16 GT/s, PCIe Gen4 provides double the bandwidth of PCIe Gen3, supporting backward compatibility and future hardware upgrade.
Half-height, Half-length (HHHL)
AI Accelerator with Multiple
VPU Processors
Edge AI Accelerator with
Multiple Edge TPUs
The QM-GK series supports both M.2 NVMe SSD and 2.5-inch SATA storage, offering flexible solutions for diversified data storage demands. For real-time data processing scenarios including machine vision, surveillance and factory automation, the PCIe Gen3 x4 NVMe slot with 32Gbps bandwidth delivers excellent performance for AI and data analysis workloads.
Dual LAN design enables network redundancy with alternative communication paths. Automatic failover activates standby link instantly when primary network fails, minimizing downtime and guaranteeing continuous industrial operation.
Two full-speed 2.5GbE ports provide abundant bandwidth for simultaneous connection to industrial sensors, high-resolution cameras and various Ethernet IoT peripherals.
2.5GbE bandwidth is 2.5x faster than standard 1GbE Ethernet, delivering higher throughput for high-resolution camera streaming and 4K/8K video processing workloads.
The industrial panel PC is equipped with four RS-232 ports and one configurable RS-232/422/485 port to connect legacy factory automation equipment. RS-485 supports Automatic Flow Control (AFC) to prevent buffer overflow and avoid data loss during long-distance serial communication.
QM-GK reserves six high-speed USB interfaces supporting transfer speed up to 10Gbps. It easily connects high-resolution industrial cameras, human input devices and edge IoT sensors to realize stable high-speed data acquisition.
The QM-GK supports standard 100x100 VESA mounting for monitor arm and wall installation. Besides, Qtenboard optimized panel mounting structure uses fewer fasteners for quick hand assembly without extra tools.
Panel Mount
Wall Mount
Arm Mount
Stand Mount
Industrial Automation
AI AOI(Automated Optical Inspection)
Retail Analytics
Industrial Automation
